- Measuring Method: Nephelometric 90° scattered light
- Light Source: LED
- Measuring Range: 0.0001 to 100.00 NTU
- Accuracy: ±2% of reading or 0.02 NTU, whichever is greater
- Display Resolution: 0.0000 – 9.9999 NTU; 0.0001 NTU
- Display Resolution: 10.000 – 100.00 NTU; 0.001 NTU
- Water Flow Rate: 100 – 200 mL/min
- Water Temperature: 0 to +40°C
- Operating Temperature: -20 to +50°C ; Humidity 95% RH or less
- Main Materials: PP-GF AES SUS316L
- Cable Length: 3 m
Low Turbidity – P-J001
Leadtec Turbidity and Suspended Solids Family is the long-awaited solution to your turbidity and suspended solids measurement.
The measuring principle of the sensors is based on 90º Nephelometry light scatter. The scattered light is measured by the sensing elements in which had a fixed measurement angle of 90º from the particles in the water.
Each sensor was designed in such a way to cover every ranges of measurement, from the cleanest ultrapure water to the dirtiest industrial effluents with uncompromising
accuracy.
